The Kingspan KS1000RW / KS2000RW is the perfect composite panel for pitched roofs, horizontal and vertical wall applications. The trapezoidal Kingspan KS1000RW roof panel is best for industrial or commercial buildings, as well as public-purpose buildings.

Why choose the KS1000RW Kingspan?

Aside from its application use, KS1000RW Kingspan is one of the best insulated wall panels on the market. It is robust, suitable for a range of varied applications, and offers long life as a part of your project. You will benefit from:

• Quick and easy installation
• Exceptional thermal performance
• Superior Fire Ratings
• Improved visual appearance
• Insulation continuity

The Kingspan Trapezoidal (KS1000 RW) insulated wall panel is available in 1000mm or 2000mm widths and in lengths of up to 29m (depending on width). This allows for a super-fast, stress-free installation on both vertical and horizontal surfaces. Installation need not be a chore, and this product will help you to you save time and effort that could be better spent on other things.

Minimum Pitch: 4deg

 Lengths: KS1000RW from 1800mm to 29m & KS2000RW Up to 20m

 Cover Width: 1000mm & 2000mm

 Colours: XL Forte & Spectrum

Downloads

Datasheet

Kingspan External Colour and Coating Brochure

Kingspan KS1000 RW Roof Panel Installation Guide

Kingspan KS1000 RW Roof Panel Installation Guide (FAWS)

Kingspan KS1000RW prices

Being an approved Kingspan composite supplier, we can source roof panels and KS1000RW wall panels at a competitive price. When you speak to us, you’ll find that we have a wealth of knowledge you can tap straight into. Our clients find this particularly helpful during the specification process. Whether you have queries about spec, lead times, availability, application, or anything else, Prestige is here to ensure you have the correct information at your disposal.

To place an order or speak with us about Kingspan KS1000RW prices and product availability, simply call us on 01268 858444. Our team of experts love to talk shop with our customers, so don’t hesitate to get in touch today.

The post KS1000 RW / 2000 RW (Trapezoidal Profile) appeared first on Prestige Industrial Roofing Supplies.

The Kingspan KS1000LP Low pitch panel is a shallow profiled, composite panel with insulation and has raised side joints, enabled by a secret-fix appearance created by elevated and capped fastners. The steel Kingspan KS1000LP low pitch panel is perfect for all roof builds with a pitch after the deflection is 1.5 or greater.

 Profiles: Kapture profile along panel side joint with minor profiles across the panel width
Fixing detail: Secret-fix appearance created by elevated and capped fastners clipped on site
Metal type: Steel
Colours: Kingspan XL Forte and Kingspan Spectrum.
Application: Pitched roofs of 1.5° or more after deflection
Lengths: From 1.8m to 29m
Cover width: 1000mm
Product compatibility: Integrates with Kingspan Day-Lite Kapture, Kingspan Safety solutions and Kingspan Roof Mounted PV System.

Downloads

Brochure

Installation Guide

The post KS1000 LP (Low Pitch Panel) appeared first on Prestige Industrial Roofing Supplies.

The Kingspan Topdek KS1000TD is a flat, single-ply composite panel. This high performing flat, single PVC membrane panel has a trapezoidal steel deck – suitable for flat and pitched roofs of 0.72 or greater. The Kingspan Topdek KS1000TD, also comes with an optional standing seam aesthetic and has a secret fix appearance.

 Profiles: Flat single-ply PVC / TPE membrane, with optional standing seam aesthetic
Core: QuadCore™
Fixing detail: Secret-fix appearance

Sheet Lengths 2m – 14.5m Long
Application: Membranes
Lengths: Flat and pitched roofs above 1:80 (0.72°) after deflection
Cover width: 1000mm
Product compatibility: Integrates with Kingspan Safety Solutions and Kingspan Roof Mounted PV System

Downloads

Datasheet

The post KS1000TD (Topdek) appeared first on Prestige Industrial Roofing Supplies.

Kingspan PoweRail RW

Downloads

Brochure

The post KS1000RW Powerail appeared first on Prestige Industrial Roofing Supplies.

PowerPanel combines high performance QuadCore thermal efficiency and leading photovoltaic technology – creating a single solution to future-proof buildings. PowerPanel is one of the first systems globally to earn the FM Approved mark to FM 4478, meeting rigorous performance tests for fire, hail, wind uplift, and snow loading. PowerPanel blends high performance with a sleek, slimline design to enhance building aesthetics.

Product Highlights

• Tested to FM 4478 standard
• U-values as low as 0.11 W/m2K
• QuadCore Technology insulation core and module energy output of up to 475Wp
• Suitable for pitched roof application of 4° or more after deflection
• Standard lengths from 3 – 18 m. See technical information for non-standard lengths available
• Factory-controlled manufacturing
• Insurance-backed system Warranty

Downloads

Datasheet

The post KS1000 Powerpanel appeared first on Prestige Industrial Roofing Supplies.

The Kingspan KS1000RT roof tile effect panel is a composite panel that could be mistaken for a traditional tiled roof however it is an advanced insulated panel with a shaped outer that works better than any current tiling material. Available in a range of colours, the Kingspan tile effect panel is built with insulation and can be used for any domestic or commercial building with a pitched roof of 12 degrees or more after deflection.

The tile effect panel provides a traditional look but hides an advance system which is easy to assemble and complies with all current building regulations and standards.

 Profiles: Pantile effect
Fixing detail: Through-fix
Metal type: Steel
Colours: Kingspan XL Forte (Anthracite and Copper Beech only) and Kingspan Destral.
Application: Pitched roofs of 12° or more after deflection
Lengths: From 2.1m to 15.75m
Cover width: 1000mm
Product compatibility: Integrates with Kingspan Day-Lite Upstand and Kingspan Saferidge Safety Solutions

Downloads

Brochure

The post KS1000 RT (Roof Tile Effect Panel) appeared first on Prestige Industrial Roofing Supplies.

The KS1000 SRW is a sinusoidal profiled insulated roof and wall panel with a through-fix type fixing system. The composite panels can be used for building applications and roof pitches of 4 degrees or more after deflection.

KS1000SRW Composite roof panels offer significant advantages over conventional systems as they are fast to install and provide superior thermal and insulation properties. Air leakage is kept to a minimum and they eliminate cavity condensation and cold bridging.

Downloads

Datasheet

The post KS1000 SRW (Sinusoidal Panel) appeared first on Prestige Industrial Roofing Supplies.
