The Kingspan KS1000 RW / KS2000 RW is the perfect composite panel for pitched roofs, horizontal and vertical wall applications. The trapezoidal roof panel KS1000 RW / KS2000RW is best for industrial or commercial buildings as well as public purpose buildings.

Why choose Kingspan KS1000RW?

Aside from its application use, KS1000RW Kingspan is one of the best insulated wall panels on the market and offers:

• Quick and easy installation
• Exceptional thermal performance
• Superior Fire Ratings
• Improved visual appearance
• Insulation continuity

The Kingspan Trapezoidal (KS1000 RW) insulated wall panel is available in 1000mm or 2000mm widths and in lengths of up to 29m (depending on width). This allows for a super-fast installation on both vertical and horizontal surfaces.

Minimum Pitch: 4deg

 Lengths: KS1000RW from 1800mm to 29m & KS2000RW Up to 20m

 Cover Width: 1000mm & 2000mm

 Colours: XL Forte & Spectrum

Downloads

Brochure

Datasheet

Kingspan KS1000RW prices

Being an approved Kingspan composite supplier, we can source Kingspan KS1000RW roof panels and KS1000RW wall panels at a competitive price.

When you speak to us about KS1000RW Kingspan insulated panels, you’ll find that we have a wealth of knowledge you can tap straight into. Our clients find this particularly helpful during the specification process.

To place an order or speak with us about Kingspan KS1000RW prices and product availability, simply call us on 01268 858444.

The post KS1000 RW appeared first on Prestige Industrial Roofing Supplies.

The KS1000MR Architectural Wall Panels from Kingspan are high-performance secret-fix wall panels designed for architects seeking maximum design flexibility. Ideal for both vertical and horizontal applications, these panels offer durability, long-span capability, and an aesthetically seamless finish. The KS1000MR panel is perfect for commercial, industrial, and architectural projects where performance meets visual appeal.

Profiles Available: Curvewall, Convex, Euro-Box, Flat, Flat-Stucco, Louvre, Mini-Micro, Micro-Rib, Plank, Tramline, Wave
Fixing Detail: Secret-fix
Metal Type: Steel
Lengths Available: From 1.8m to 17m
Cover Width: 600mm – 1000mm
Spanning Capability: Longspan – up to 8.2m, frame to frame
Panel Code: KS1000MR

Technical Specifications – KS1000MR:

• Thermal Insulation: [Insert U-value if available, e.g., 0.25 W/m²K]

• Thickness Options: [Insert if applicable, e.g., 50mm, 75mm, 100mm]

• Fire Rating: [Insert rating if available]

• Durability: Corrosion-resistant steel, coated for long-term performance

• Applications: Commercial façades, industrial buildings, office complexes, sports facilities

Panel Codes-KS1000MR, KS1000MM, KS1000FL, KS1000PL, KS1000WV, KS1000EB, KS1000FL-S, KS1000LV

Why Choose KS1000MR?

KS1000MR Architectural Wall Panels combine aesthetic appeal with high performance. Secret-fix installation ensures a smooth façade, while steel construction provides durability and longevity. Available in multiple profiles and lengths, KS1000MR panels allow architects and contractors to achieve precise design visions efficiently.

Downloads

Datasheet

Panel Clamp Assembly Installation Guide

AWP Wall Panel Installation Guide – Horizontal Installation

AWP Wall Panel Installation Guide – Vertical Installation

The post Architectural Wall Panels “AWP” appeared first on Prestige Industrial Roofing Supplies.

Standard length from 3000 to 10000 mm (step 1000 mm

Standard Width 1000 mm

Steel grade S 280 GD

Outer sheet slate effect profiled steel in 0,50 mm thickness

Inner sheet standard liner profiled steel

Coatings Grandem RAL 7024 mat

Installation horizontal

Downloads:

MR078_JI-Slate-1000SF-PIR-Installation-guide

The post Joside JI Slate 1000SF appeared first on Prestige Industrial Roofing Supplies.

Product Highlights

• Available in flat (F5 Extra) or satin line (S5 Extra) profile
• Length: 1800mm up to 12500mm
• Panels <1800mm long can be supplied subject to an extra charge
• Lengths subject to verification for fire/structural performance
• Width: From 600mm to 1200mm (UK and Mainland Europe)
• 1000mm maximum width for export using shipping containers
• Can be installed horizontally or vertically
• 0.5mm or 0.7mm external steel face, in a range of coatings and colours
• 0.5mm or 0.7mm internal steel face, in a range of coatings and colours
• 115kg/m³ density stone wool core
• CE-marked to EN 14509:2013
• Secret-fix interlocking 5mm joint, creating a seamless finish

The post Eurobond Euro Panel F5 appeared first on Prestige Industrial Roofing Supplies.

The Joriside JI Roof 1000 LPCB certified Trapezoidal insulated roof panel is a composite panel best suited to pitched roofs, horizontal or wall application as well as external insulated cladding. The Joriside JI1000 Roof is best used for industrial, commercial and public buildings.

 Panel have a metal outer and inner sheet to provide strength and thermal resistance over large spans.

 Jorside JI1000 box profile panels are to be installed on roofs with a minimum pitch fo 4 degrees after deflection.

Lengths Available (mm) 2550 to 13600

Panel Thickness (mm) 40 / 60 / 80 / 100 / 120 / 150

Coating Options Polyester, Plastisol C200,HPS200, Polyuréthane, PVDF.

Downloads

Colorcoat® LG Colour card

The post Joriside JI1000 Trapezoidal Wall appeared first on Prestige Industrial Roofing Supplies.

Lengths Available (mm) 2550 to 13600

Panel Thickness (mm) 30 / 40 / 60

Coating Options Polyester, Plastisol C200,HPS200, Polyuréthane, PVDF.

Downloads

JI-Eco-PIR

Colorcoat® LG Colour card

The post Joriside JI Eco Panel (Wall) appeared first on Prestige Industrial Roofing Supplies.

 The TATA Trisomet 333 Roof Panel is a single component, insulated panel manufactured suitable for both roof and wall cladding applications. This composite panel has been built as a one fix component therefore it is able to be installed quickly. This box profile panel works with the wide spaced trapezoidal steel external skin providing enhanced performance for water drainage, strength and walkability.

Downloads

Brochure

Colorcoat Prisma Colour Card

Colorcoat LG Colour Card

The post Trisomet 333 Composite Roof/Wall Panel appeared first on Prestige Industrial Roofing Supplies.

The TATA Trimapanel for walls is a micro-rib insulated, secret fix, composite panel with a unique and bespoke “secret fix” joint allowing it’s primary fixings to be hidden from view. This gives the TATA composite panel a completely smooth, high end finish providing an architecturally impressive look.

Available in a variety of thicknesses, shapes and sizes – the Trimapanel flat panel can be cut to bespoke lengths up to 12m to minimize wastage during the construction process.

Insulation Thicknesses available include 70mm, 90mm and 120mm to provide U-values down to 0.17W/m2K.

This composite panel comes in a range of colours and can also be laid both vertically and horizontally allowing design flexibility for architects and designers.

Downloads

Colorcoat HPS200 Ultra Colour Card

Colorcoat LG Colour Card

Colorcoat Prisma Colour Card

Brochure

The post Trima-panel Micro-Rib appeared first on Prestige Industrial Roofing Supplies.

Kingspan Evolution AXIS 1000 (KS1000 Optimo) is a sleek rainscreen facade designed for flat surface areas. Panels provide single point installation with the secret fix system.

The system meets or exceeds all the statutory regulation criteria, such as structural, thermal, acoustic and durability performance, offers a sustainable rated solution and, most importantly of all, provides life and property fire safety protection.

QuadCore™ Evolution Axis is a highly streamlined, unprofiled insulated panel system; Ideal solution for architects and designers aiming to achieve a minimalist facade on buildings with large flat surface areas.

Benchmark by Kingspan can be used for both horizontal and vertical applications.

600-1000mm Modules

Profiles: Flat
Fixing detail: Secret-fix appearance
Metal type: Steel
Colours: Available in Kingspan Spectrum (Solid / Metallic / Diamond) and Kingspan Altaris.
Application: Suitable for vertical or horizontal application
Lengths: From 1.8m to 17m
Cover width: 600mm to 1000mm
Product compatibility: Integrates with AWP, as well as with Kingspan Day-Lite Architectural
Pre-formed corners and panels: Panels can be curved on the length or width and corners can be cranked

Downloads

Brochure

Installation Guide

Datasheet

The post Evolution Axis 1000 (Optimo) Panel appeared first on Prestige Industrial Roofing Supplies.

 The TATA Trimapanel for walls is a Flat insulated, secret fix, composite panel with a unique and bespoke “secret fix” joint allowing its primary fixings to be hidden from view. This gives the TATA composite panel a completely smooth, high end finish providing an architecturally impressive look.

 Trimapanel® flat is available in a range of different colours using Colorcoat HPS200 Ultra® pre-finished steel

Available in a variety of thicknesses, shapes and sizes – the Trimapanel flat panel can be cut to bespoke lengths up to 12m to minimize wastage during the construction process.

 Insulation Thicknesses available include 70mm, 90mm and 120mm to provide U-values down to 0.17W/m2K.

 This composite panel can also be laid both vertically and horizontally allowing design flexibility for architects and designers.

Downloads

Colorcoat HPS200 Ultra Colour Card

Colorcoat LG Colour Card

Colorcoat Prisma Colour Card

Datasheet

The post Trima-panel Flat appeared first on Prestige Industrial Roofing Supplies.
